The complete line for PCB Prototyping

Research & In-house PCB Prototyping

The complete line
for PCB Prototyping

PCB prototyping process steps

Coordinated methods and tools from a single source

From structuring of the base material to complex production-level multilayers the entire prototyping process -- design, production, testing and optimization -- can be completed in a single day.

From layout data to fully functional PCB

LPKF offers easy-to-use, compatible solutions for all process steps.

Software with intuitive operation

Simple data preparation and machine control.

PCB structuring

Conductive tracks made by mechanical or laser-based systems within minutes.

PCB drilling

Drilling of through-holes and blind vias.

Through-hole plating

Through-hole plating without chemicals or with electroplating solutions.

PCB depaneling

Singulation of PCBs from larger panels for a wide range of PCB materials.

SMT / Finishing

Component population and professional finishing of PCB prototypes and small series.


Production of high-grade multilayer PCBs with up to eight layers in-house.


Rapid PCB Prototyping Product Catalog (pdf - 4 MB)
LPKF TechGuide PCB Prototyping (pdf - 3 MB)

Training courses make the start simple

LPKF systems can be operated easily and intuitively

Detailed and understandable manuals lead and support the user during the installation, start-up and operation of the machines and software programs.

LPKF ProtoLasers are always installed by LPKF's own engineers. The user is familiarized with the possibilities of the system in a short training course.

We also offer installation and training for the smaller systems.  This training can be done at LPKF's premises or at your facility.
